ML211
Thermal Energy PID Monitor
Reliable
BTU monitoring with no moving parts.
ML211
- Suitable
for hot and chilled water energy monitoring.
- Single
source responsibility on all components.
- Measures
five variables: flow rate, thermal energy, T-in, T-out and T.
- 8-line
x 16-character back-lit LCD display.
- 3-position
membrane keypad.
- Two
energy totalizers.
- Direct
RTD inputs.
- 4-20mA
current, RS485 outputs.
- Programmable
alarm and digital inputs.
- Empty
pipe detection.
- Integral
diagnostic functions.
- Programmable
through Keypad, PC or hand terminal.
- Dual
Range.
- Panel,
wall and direct sensor mount
FIND OUT MORE
TYPICAL
PRODUCT APPLICATIONS
- Heating
- Chillers
- Boilers
- Heat
Exchangers
- Sub
Metering
|
- District
Heating
- University
Monitoring
-
Air Conditioning
- Process
Control
|
MS1000
1" through 16" sizes for flows
from 2.45 to 20,698 gpm. Standard pressure is 230 PSI @ 70°
F. Polypropylene, Ebanite or PTFE liner. Low cost, easy to install
wafer mounting. Fluid temperatures up to 302°F. |
|
MS2500
1" through 42" sizes for
flows from 2.45 to 142,619 gpm. Standard pressure is 230 PSI
@ 70°F. Temperatures up
to 300° F. Polypropylene, Ebanite or PTFE liner. |
|
MS3770
Insertion Flowmeter
3" through 80" pipe diameters
for flows from 66 gpm to 517,440 gpm - pressures to 235 PSI.
Temperatures up to 300° F. Insertion design can be installed
and removed under pressure (when equipped with ball valve). |
|
